7 Inch 800×480 RGB Interface LCD Display Module
This 7-inch LCD display module features a resolution of 800×480 with an RGB interface, offering stable performance and clear image quality. It is designed for embedded and industrial applications, supporting reliable signal transmission and easy integration with various control boards. The module ensures low power consumption and long operational life, making it suitable for continuous use environments.
Share：
Industrial control systems
HMI (Human-Machine Interface)
Smart home control panels
Medical equipment
Embedded devices
| Item | Specifications | Unit |
| Part No. | EQT700CYJ012L | Unit |
| Size | 700 | inch |
| Resolution | 800*480 | – |
| Viewing Angle | 6 o’clock | – |
| Active Area | 154.08(H)×85.92(V) | mm |
| Outline Dimension(mm) | 165(W)×100(H)×7.25(D) | mm |
| Driver IC | EK9713CA+EK73202AB2 | – |
| Touch Function | WITHOUT | – |
| Brightness(Cd/m2) | 400 | Cd/m2 |
| Interface | RGB | – |
| Storage Temp. | －30 TO 80 | ℃ |
| Operation Temp. | －20 TO 70 | ℃ |
