2.99 inch TFT LCD Screen – High Brightness |260*800 Resolution
The 2.99 inch TFT LCD display delivers high brightness, wide viewing angles, and vivid color reproduction. With excellent sunlight readability and stable performance, it is designed for compact devices requiring clear visual output and long-term durability. The slim profile makes it easy to integrate into modern consumer electronics and industrial applications.
Share：
Smart home control panels
Portable medical monitoring devices
Handheld industrial terminals
IoT equipment and security devices
Compact smart appliances
| Spec | Item | Specifications | Unit |
| Part No. | EQT299HYZ007G | – | |
| Size | 2.99 | inch | |
| Resolution | 260*800 | – | |
| Viewing Angle | Full | – | |
| Active Area | 24.12(H)×72(V) | mm | |
| Outline Dimension(mm) | 29.88(H)×143.46(W)×3.28(D) | ||
| Driver IC | ST7701S/CST328(TFT) CST328(CTP) | – | |
| Touch Function | CTP | – | |
| Brightness(Cd/m2) | 700 | Cd/m2 | |
| Interface | SPI/RGB | – | |
| Storage Temp. | －40 TO 70 | ℃ | |
| Operation Temp. | －20 TO 60 | ℃ |
