6.86 Inch TFT LCD Display 480×1280 with Touch Screen Module for Smart Terminals
The 6.86 inch TFT LCD module features a 480×1280 resolution with integrated touch functionality, providing smooth operation and clear visual performance. Designed for interactive applications, this display combines responsive touch control with stable image quality, offering a practical solution for multifunctional smart devices. Its durability and adaptability make it suitable for both consumer and industrial-grade products.
Share：
Smart control panels with touch input
Portable industrial equipment
Handheld medical devices
Smart home terminals and IoT devices
POS machines and retail electronics
Automotive auxiliary displays
| Spec | Item | Specifications | Unit |
| Part No. | EQT686DKU002P | – | |
| Size | 6.86 | inch | |
| Resolution | 480×1280 | – | |
| Viewing Angle | Full | – | |
| Active Area | 160.512(H)×60.192(V) | mm | |
| Outline Dimension(mm) | 66.8(W)×181.2(H)×6.75(D） | ||
| Driver IC | CNL9707 | – | |
| Touch Function | CTP | – | |
| Brightness(Cd/m2) | 500 | Cd/m2 | |
| Interface | MIPI | – | |
| Storage Temp. | －30 TO 70 | ℃ | |
| Operation Temp. | －20 TO 60 | ℃ |
